Gravety Conveyor Rollers– Smooth, Efficient, and Reliable Material Flow
Features
Precision bearings sealed in polyamide bearing housing
Noise Free
Protects from dust and splashed water
Suits for all applications (Universal)
Designed for light, medium, heavy loads
| Tube Dia x Thk | Shaft Dia | Steel Z/P | SS |
|---|---|---|---|
| 38.1 × 1.2 | 10 / 12 / 11Hex | o | o |
| 50.0 × 1.5 | 12 / 15 / 11Hex | o | o |
| 50.8 × 1.5 | 12 / 15 | o | o |
| 60.3 × 2.0 | 12 / 15 / 11Hex | o | o |
| 60.3 × 3.0 | 17 | o | o |
| 76.2 × 3.0 | 20 | o | o |
| 88.9 × 3.0 | 20 / 25 | o | o |
Features
Polypropylene bearing housing made of steel or stainless steel balls
Smooth & Free Running
For Light weight and medium load products
Cost efficient
| Tube Dia x Thk | Shaft Dia | Steel Z/P | SS |
|---|---|---|---|
| 31.75 × 1.2 | 8 | o | o |
| 38.1 × 1.2 | 10 | o | o |
| 50.0 × 1.5 | 12 / 11Hex | o | o |
Features
Precision bearings permanently housed in pressed sheet metal cap
Used in high & low temperature application
Bears light and medium loads
Anti-Static
| Tube Dia x Thk | Shaft Dia | Steel Z/P | SS |
|---|---|---|---|
| 38.1 × 1.2 | 12 | o | o |
| 50.0 × 1.5 | 12 / 15 | o | o |
| 50.8 × 1.5 | 12 / 15 | o | o |
| 60.3 × 2.0 | 12 / 15 | o | o |
| 76.2 × 3.0 | 15 / 20 | o | o |
Features
Semi-precision pressed sheet bearing
housing made of steel balls
Free running bearings
Used in high & low temperature application (- 20° C to + 80° C)
For Light weight and medium load application
Cost efficient
| Tube Dia x Thk | Shaft Dia | Steel Z/P |
|---|---|---|
| 38.1 × 1.2 | 8 | o |
| 50.0 × 1.5 | 12 / 11Hex | o |
| 60.3 × 2.0 | 12 / 11Hex | o |
